DougM Newbie

Joined: 28 Jul 2009 Posts: 60 Location: Alliance, Ohio
|
Posted: Mon Sep 21 09 12:58 am Post subject: Filling bad welds for appearances |
|
|
After a ugly weld has been put on is there
any thing that can be used to fill and
cover over the weld ?
I have a grinder but do not want to use it
Help _________________
Char-Griller duo 5050 |
|
Back to top |
|
 |
k.a.m. BBQ Mega Star

Joined: 12 Dec 2007 Posts: 26012 Location: Southeast Texas.
|
Posted: Mon Sep 21 09 1:10 am Post subject: |
|
|
Doug, are you talking about porosity (pin holes ) do you have a pic of said welds? I am not sure if you have any but a tiger disc will sort of dress up a weld and improve its looks. But pics will help. _________________ Always remember slow and steady wins the race.
Hybrid Cooker |
|
Back to top |
|
 |
DougM Newbie

Joined: 28 Jul 2009 Posts: 60 Location: Alliance, Ohio
|
Posted: Mon Sep 21 09 1:19 am Post subject: |
|
|
I would call them POT HOLES  _________________
Char-Griller duo 5050 |
|
Back to top |
|
 |
seattlepitboss BBQ Pro
Joined: 28 Oct 2008 Posts: 573 Location: Seattle, Washington
|
Posted: Mon Sep 21 09 1:24 am Post subject: Re: Filling bad welds for appearances |
|
|
DougM wrote: | After a ugly weld has been put on is there
any thing that can be used to fill and
cover over the weld ?
I have a grinder but do not want to use it |
Butt welds can be conveniently dressed with a flap wheel on an angle grinder, much different than grinding with a stone. Fillet welds are much harder. I take a 1/4" thick grinding wheel and just gently hit the high spots and lumps. I take a small sharp chisel and a hammer and cleanly remove all the dingleberries and power wire brush. Worst case on fillets, you can Bondo and sand before painting.
Heat it and beat it; grind it and paint it. Those are the watchwords of home shop welders everywhere. If you don't want to let your dingleberries and uglumps show, you gotta pay the price and clean them up.
seattlepitboss |
|
Back to top |
|
 |
DougM Newbie

Joined: 28 Jul 2009 Posts: 60 Location: Alliance, Ohio
|
Posted: Mon Sep 21 09 1:31 am Post subject: |
|
|
i DO NOT like to post how bad it is  _________________
Char-Griller duo 5050 |
|
Back to top |
|
 |
k.a.m. BBQ Mega Star

Joined: 12 Dec 2007 Posts: 26012 Location: Southeast Texas.
|
Posted: Mon Sep 21 09 1:32 am Post subject: |
|
|
Doug, my only advice is you can put your grinder on edge and take out the pockets then lay another bead on top. If you weld dirty metal this happens, also if you do not clean a weld and cap it with flux left behind it will also cause this. Or these could be caused from moving to fast and causing breaks in your weld. I do not recommend Jb-weld or any fillers, taking down the weld a little and capping are a pretty quick fix. _________________ Always remember slow and steady wins the race.
Hybrid Cooker |
|
Back to top |
|
 |
DougM Newbie

Joined: 28 Jul 2009 Posts: 60 Location: Alliance, Ohio
|
Posted: Mon Sep 21 09 1:39 am Post subject: |
|
|
Well here they are for the world to seeeeeeee
 _________________
Char-Griller duo 5050 |
|
Back to top |
|
 |
k.a.m. BBQ Mega Star

Joined: 12 Dec 2007 Posts: 26012 Location: Southeast Texas.
|
Posted: Mon Sep 21 09 1:48 am Post subject: |
|
|
Doug, my advice is go to your local welding supply and get some 4.5'' 40 grit tiger discs or flapper wheel whatever you want to call them. And then take down your highs, you Will be surprised how much it will improve the look. Hey you are learning and it takes practice, do not cut yourself short. I am not going to critique your welds only try to help you end up with something you can work with. _________________ Always remember slow and steady wins the race.
Hybrid Cooker |
|
Back to top |
|
 |
Tom C BBQ Super Pro

Joined: 21 Jul 2007 Posts: 1851 Location: N. California
|
Posted: Mon Sep 21 09 2:39 am Post subject: |
|
|
DougM,
K.A.M. is spot on! If I had a dollar for every ugly weld I made during my smoker build I could have paid for the build with money to spare.
Just clean it up the best you can. Odds are you'll be thrilled with how it will look with paint on it! Keep going, you're doing fine. _________________ Homemade offset smoker 24"x48"
Charbroil CB900 grill |
|
Back to top |
|
 |
HillbillySmoker BBQ Pro

Joined: 25 May 2008 Posts: 917 Location: WV
|
Posted: Mon Sep 21 09 4:11 am Post subject: |
|
|
My advice would be what the others have suggested, take a 40 grit flapper disc and smooth it down with the grinder the best you can, after that you could take a putty knife and fill the voids with JBWeld like caulking an old window. but you would have to grind it down so that the putty knife will contact the flat strap and the door without hitting any weld to create a nice smooth appearance. _________________ Patio Smoker Grill
My Smoker Grill build |
|
Back to top |
|
 |
QDawg
Joined: 01 Sep 2009 Posts: 15
|
Posted: Mon Sep 21 09 4:24 am Post subject: |
|
|
Could you put furnace cement on there and fire up the grill to cure it? That stuff gets rock hard, but with it being on the door I don't know if it would pop of with the vibration of closing? I have used it on my wood stove for the door gaskets and it works great for that. I used "Heat Safe", I belive I bought it from Sutherlands (A lacalk lumberyard). On your welds, I am not going to critisize your welds either. But, I will give you some advice. It looks like you either had your wire speed to slow or you was trying to go to fast. If you was getting a steady crackling sound like frying bacon (wire speed OK) then you was probably going to fast. If it sounds interupted, like you was having power, then not, then power again then it was probably your wire feed speed. Turns up your feed speed, if your speed gets to fast it will push your gun away from the work. If that happens, turn your speed back just a bit. The migs will work better with a faster speed than they will with too slow of speed. It is real easy to get in to big of a hurry when welding. I guess welding is kind of like Q'ing. Q'ing "Slow and low". Welding "Slow and hot". Good luck on your build.
QDawg ><> |
|
Back to top |
|
 |
DougM Newbie

Joined: 28 Jul 2009 Posts: 60 Location: Alliance, Ohio
|
Posted: Mon Sep 21 09 7:56 am Post subject: |
|
|
Thanks guy's I am grinding now  _________________
Char-Griller duo 5050 |
|
Back to top |
|
 |
HillbillySmoker BBQ Pro

Joined: 25 May 2008 Posts: 917 Location: WV
|
|
Back to top |
|
 |
jlaudio29 Newbie
Joined: 09 Sep 2009 Posts: 68
|
Posted: Mon Sep 21 09 9:07 am Post subject: |
|
|
Are those mig welds or stick welds? |
|
Back to top |
|
 |
Smoked Up BBQ Fan
Joined: 16 Feb 2009 Posts: 105
|
Posted: Mon Sep 21 09 9:47 am Post subject: |
|
|
k.a.m. wrote: | I am not going to critique your welds... |
I'm not so sure you are doing him any favors by not critiquing them. What if he gets his smoker put together, painted, and it falls apart? To me, those welds don't appear to hold anything, just a bunch of splatter. I'm not trying to be ugly here, but somebody needs to help this guy. |
|
Back to top |
|
 |
HillbillySmoker BBQ Pro

Joined: 25 May 2008 Posts: 917 Location: WV
|
|
Back to top |
|
 |
k.a.m. BBQ Mega Star

Joined: 12 Dec 2007 Posts: 26012 Location: Southeast Texas.
|
Posted: Mon Sep 21 09 10:07 am Post subject: |
|
|
Smoked Up, if and when Doug asks me to critique his welds I will be more than glad to give my opinion, with a long list of questions of his process and methods but till then, He asked how to dress up some bad looking welds. For him and many others on the ring welding is a new field as I have stated many times over, building a cooker is one thing putting it on a homemade trailer with no welding experience is another and I do not recommend this. The fact is if he hit home on that strap at least 40% with solid tacks it will hold. So I Will concentrate on the positive and try to help him get through this build. _________________ Always remember slow and steady wins the race.
Hybrid Cooker |
|
Back to top |
|
 |
Jeff T BBQ Super Pro

Joined: 08 Mar 2005 Posts: 4207 Location: Norfolk, Nebraska
|
Posted: Mon Sep 21 09 12:56 pm Post subject: |
|
|
Aint nothing wrong with those welds.... touch em up with your grinder, you`ll be fine. Your not sitting in the cooker driving down the road waiting for careless drivers.
Your doing fine Doug! |
|
